dds::topic::TopicDescription Class Reference

This class is the base for Topic, ContentFilteredTopic and MultiTopic. More...

#include "TopicDescription.hpp"

Inheritance diagram for dds::topic::TopicDescription:
Inheritance graph

Public Member Functions

const dds::domain::DomainParticipant & domain_participant () const

bool is_nil () const

const std::string & name () const

template<typename R >
bool operator!= (const R &ref) const

bool operator!= (const null_type nil) const

DELEGATE * operator-> ()

const DELEGATE * operator-> () const

template<typename R >
bool operator== (const R &ref) const

bool operator== (const null_type) const

const std::string & type_name () const


Detailed Description

This class is the base for Topic, ContentFilteredTopic and MultiTopic.

The TopicDescription attribute type_name defines an unique data type that is made available to the Data Distribution Service when a Topic is created with that type.
TopicDescription has also a name that allows it to be retrieved locally.

See also
Topic Definition

Definition at line 47 of file TopicDescription.hpp.

Member Function Documentation

◆ domain_participant()

const dds::domain::DomainParticipant & dds::topic::TopicDescription::domain_participant ( ) const

This operation returns the DomainParticipant associated with the TopicDescription.

Note that there is exactly one DomainParticipant associated with each TopicDescription.

Returns
the DomainParticipant

Definition at line 62 of file TopicDescriptionImpl.hpp.

◆ is_nil()

template<typename DELEGATE >
bool dds::core::Reference< DELEGATE >::is_nil ( ) const
inherited

Check if the referenced object is nil.

In other words, check if the reference is pointing to a null object.

Returns
true if the referenced object is null.

Definition at line 143 of file ReferenceImpl.hpp.

◆ name()

const std::string & dds::topic::TopicDescription::name ( ) const

This operation returns the name used to create the TopicDescription.

Returns
the TopicDescription name

Definition at line 46 of file TopicDescriptionImpl.hpp.

◆ operator!=() [1/2]

template<typename DELEGATE >
template<typename R >
bool dds::core::Reference< DELEGATE >::operator!= ( const R &  ref) const
inherited

Compares two Reference objects and returns true if they are not equal.

Inequality is based on the referential inequality of the object being pointed to.

Parameters
refthe other Reference object
Returns
true when not equal

Definition at line 100 of file ReferenceImpl.hpp.

◆ operator!=() [2/2]

template<typename DELEGATE >
bool dds::core::Reference< DELEGATE >::operator!= ( const null_type  nil) const
inherited

Special operator!= used to check if this reference object does not equal the dds::core::null reference.

The non-null-check can be done like this:

if (r != dds::core::null) {
// Use the dds reference object r
}
Returns
true if this reference is not null.

Definition at line 157 of file ReferenceImpl.hpp.

◆ operator->() [1/2]

template<typename DELEGATE >
DELEGATE * dds::core::Reference< DELEGATE >::operator-> ( )
inherited

The operator->() is provided to be able to directly invoke functions on the delegate.

The decision to provide direct access to the delegate was motivated by the need for providing a way that was not invasive with respect to the CXXDDS API and yet would allow for vendor-specific extension. Thus vendor-specific extensions can be invoked on the Reference and on all its subclasses as follows:

my_dds_entity.standard_function();
my_dds_entity->vendor_specific_extension();
Returns
a reference to delegate.

Definition at line 180 of file ReferenceImpl.hpp.

◆ operator->() [2/2]

template<typename DELEGATE >
const DELEGATE * dds::core::Reference< DELEGATE >::operator-> ( ) const
inherited

The operator->() is provided to be able to directly invoke functions on the delegate.

The decision to provide direct access to the delegate was motivated by the need for providing a way that was not invasive with respect to the CXXDDS API and yet would allow for vendor-specific extension. Thus vendor-specific extensions can be invoked on the Reference and on all its subclasses as follows:

my_dds_entity.standard_function();
my_dds_entity->vendor_specific_extension();
Returns
a reference to delegate.

Definition at line 188 of file ReferenceImpl.hpp.

◆ operator==() [1/2]

template<typename DELEGATE >
template<typename R >
bool dds::core::Reference< DELEGATE >::operator== ( const R &  ref) const
inherited

Compares two Reference objects and returns true if they are equal.

Equality is based on the referential equality of the object being pointed.

Parameters
refthe other Reference object
Returns
true when equal

Definition at line 83 of file ReferenceImpl.hpp.

◆ operator==() [2/2]

template<typename DELEGATE >
bool dds::core::Reference< DELEGATE >::operator== ( const null_type  ) const
inherited

Special operator== used to check if this reference object equals the dds::core::null reference.

The null-check can be done like this:

if (r == dds::core::null) {
// Do not use the dds reference object r in its current state
}
Returns
true if this reference is null.

Definition at line 150 of file ReferenceImpl.hpp.

◆ type_name()

const std::string & dds::topic::TopicDescription::type_name ( ) const

This operation returns the registered name of the data type associated with the TopicDescription.

Returns
the type_name

Definition at line 54 of file TopicDescriptionImpl.hpp.

The documentation for this class was generated from the following files:
