The QosProvider API allows users to specify the QoS settings of their DCPS entities outside of application code in XML. More...

#include "QosProvider.hpp"

Inheritance diagram for dds::core::QosProvider:

Public Member Functions
	QosProvider (const std::string &uri, const std::string &profile)

	QosProvider (const std::string &uri)

dds::sub::qos::DataReaderQos	datareader_qos ()

dds::sub::qos::DataReaderQos	datareader_qos (const std::string &id)

dds::pub::qos::DataWriterQos	datawriter_qos ()

dds::pub::qos::DataWriterQos	datawriter_qos (const std::string &id)

bool	is_nil () const

template<typename R >
bool	operator!= (const R &ref) const

bool	operator!= (const null_type nil) const

DELEGATE *	operator-> ()

const DELEGATE *	operator-> () const

template<typename R >
bool	operator== (const R &ref) const

bool	operator== (const null_type) const

dds::domain::qos::DomainParticipantQos	participant_qos ()

dds::domain::qos::DomainParticipantQos	participant_qos (const std::string &id)

dds::pub::qos::PublisherQos	publisher_qos ()

dds::pub::qos::PublisherQos	publisher_qos (const std::string &id)

dds::sub::qos::SubscriberQos	subscriber_qos ()

dds::sub::qos::SubscriberQos	subscriber_qos (const std::string &id)

dds::topic::qos::TopicQos	topic_qos ()

dds::topic::qos::TopicQos	topic_qos (const std::string &id)

Detailed Description

The QosProvider API allows users to specify the QoS settings of their DCPS entities outside of application code in XML.

The QosProvider is delivered as part of the DCPS API of Vortex OpenSplice.

See also: QoS Provider extensive information.

Definition at line 54 of file QosProvider.hpp.

Constructor & Destructor Documentation

◆ QosProvider() [1/2]

dds::core::QosProvider::QosProvider	(	const std::string &	uri,
		const std::string &	profile
	)

explicit

Constructs a new QosProvider based on the provided uri and profile.

A QosProvider instance that is instantiated with all profiles and/or QoS’s loaded from the location specified by the provided uri.

Initialization of the QosProvider will fail under the following conditions:

No uri is provided.
The resource pointed to by uri cannot be found.
The content of the resource pointed to by uri is malformed (e.g., malformed XML). When initialization fails (for example, due to a parse error or when the resource identified by uri cannot be found), then PreconditionNotMetError will be thrown.

Look here for more information.

Parameters

uri	A Uniform Resource Identifier (URI) that points to the location where the QoS profile needs to be loaded from. Currently only URI’s with a ‘file’ scheme that point to an XML file are supported. If profiles and/or QoS settings are not uniquely identifiable by name within the resource pointed to by uri, a random one of them will be stored.
profile	The name of the QoS profile within the xml file that serves as the default QoS profile for the get qos operations.

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	When multiple thread try to invoke the function concurrently.

Definition at line 40 of file QosProviderImpl.hpp.

◆ QosProvider() [2/2]

dds::core::QosProvider::QosProvider ( const std::string & uri )

explicit

Constructs a new QosProvider based on the provided uri.

A QosProvider instance that is instantiated with all profiles and/or QoS’s loaded from the location specified by the provided uri.

Initialization of the QosProvider will fail under the following conditions:

No uri is provided.
The resource pointed to by uri cannot be found.
The content of the resource pointed to by uri is malformed (e.g., malformed XML). When initialization fails (for example, due to a parse error or when the resource identified by uri cannot be found), then PreconditionNotMetError will be thrown.

Look here for more information.

Parameters

uri A Uniform Resource Identifier (URI) that points to the location where the QoS profile needs to be loaded from. Currently only URI’s with a ‘file’ scheme that point to an XML file are supported. If profiles and/or QoS settings are not uniquely identifiable by name within the resource pointed to by uri, a random one of them will be stored.

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	When multiple thread try to invoke the function concurrently.

Definition at line 44 of file QosProviderImpl.hpp.

Member Function Documentation

◆ datareader_qos() [1/2]

dds::sub::qos::DataReaderQos dds::core::QosProvider::datareader_qos ( )

Resolves the DataReaderQos from the uri this QosProvider is associated with.

Returns: DataReadertQos from the given URI (and profile)

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no DataReaderQos can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 98 of file QosProviderImpl.hpp.

◆ datareader_qos() [2/2]

dds::sub::qos::DataReaderQos dds::core::QosProvider::datareader_qos ( const std::string & id )

Resolves the DataReaderQos identified by the id from the uri this QosProvider is associated with.

Parameters

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance. When id is NULL it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns: DataReaderQos from the given URI (and profile) using the id

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no DataReaderQos that matches the provided id can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 106 of file QosProviderImpl.hpp.

◆ datawriter_qos() [1/2]

dds::pub::qos::DataWriterQos dds::core::QosProvider::datawriter_qos ( )

Resolves the DataWriterQos from the uri this QosProvider is associated with.

Returns: DataWriterQos from the given URI (and profile)

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no DataWriterQos can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 130 of file QosProviderImpl.hpp.

◆ datawriter_qos() [2/2]

dds::pub::qos::DataWriterQos dds::core::QosProvider::datawriter_qos ( const std::string & id )

Resolves the DataWriterQos identified by the id from the uri this QosProvider is associated with.

Parameters

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance. When id is NULL it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns: DataWriterQos from the given URI (and profile) using the id

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no DataWriterQos that matches the provided id can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 138 of file QosProviderImpl.hpp.

◆ is_nil()

template<typename DELEGATE >

bool dds::core::Reference< DELEGATE >::is_nil ( ) const

inherited

Check if the referenced object is nil.

In other words, check if the reference is pointing to a null object.

Returns: true if the referenced object is null.

Definition at line 143 of file ReferenceImpl.hpp.

◆ operator!=() [1/2]

template<typename DELEGATE >

template<typename R >

bool dds::core::Reference< DELEGATE >::operator!= ( const R & ref ) const

inherited

Compares two Reference objects and returns true if they are not equal.

Inequality is based on the referential inequality of the object being pointed to.

Parameters

ref	the other Reference object

Returns: true when not equal

Definition at line 100 of file ReferenceImpl.hpp.

◆ operator!=() [2/2]

template<typename DELEGATE >

bool dds::core::Reference< DELEGATE >::operator!= ( const null_type nil ) const

inherited

Special operator!= used to check if this reference object does not equal the dds::core::null reference.

The non-null-check can be done like this:

if (r != dds::core::null) {
   // Use the dds reference object r
}

Returns: true if this reference is not null.

Definition at line 157 of file ReferenceImpl.hpp.

◆ operator->() [1/2]

template<typename DELEGATE >

DELEGATE * dds::core::Reference< DELEGATE >::operator-> ( )

inherited

The operator->() is provided to be able to directly invoke functions on the delegate.

The decision to provide direct access to the delegate was motivated by the need for providing a way that was not invasive with respect to the CXXDDS API and yet would allow for vendor-specific extension. Thus vendor-specific extensions can be invoked on the Reference and on all its subclasses as follows:

my_dds_entity.standard_function();

my_dds_entity->vendor_specific_extension();

Returns: a reference to delegate.

Definition at line 180 of file ReferenceImpl.hpp.

◆ operator->() [2/2]

template<typename DELEGATE >

const DELEGATE * dds::core::Reference< DELEGATE >::operator-> ( ) const

inherited

The operator->() is provided to be able to directly invoke functions on the delegate.

The decision to provide direct access to the delegate was motivated by the need for providing a way that was not invasive with respect to the CXXDDS API and yet would allow for vendor-specific extension. Thus vendor-specific extensions can be invoked on the Reference and on all its subclasses as follows:

my_dds_entity.standard_function();

my_dds_entity->vendor_specific_extension();

Returns: a reference to delegate.

Definition at line 188 of file ReferenceImpl.hpp.

◆ operator==() [1/2]

template<typename DELEGATE >

template<typename R >

bool dds::core::Reference< DELEGATE >::operator== ( const R & ref ) const

inherited

Compares two Reference objects and returns true if they are equal.

Equality is based on the referential equality of the object being pointed.

Parameters

ref	the other Reference object

Returns: true when equal

Definition at line 83 of file ReferenceImpl.hpp.

◆ operator==() [2/2]

template<typename DELEGATE >

bool dds::core::Reference< DELEGATE >::operator== ( const null_type ) const

inherited

Special operator== used to check if this reference object equals the dds::core::null reference.

The null-check can be done like this:

if (r == dds::core::null) {
   // Do not use the dds reference object r in its current state
}

Returns: true if this reference is null.

Definition at line 150 of file ReferenceImpl.hpp.

◆ participant_qos() [1/2]

dds::domain::qos::DomainParticipantQos dds::core::QosProvider::participant_qos ( )

Resolves the DomainParticipantQos from the uri this QosProvider is associated with.

Returns: DomainParticipantQos from the given URI (and profile)

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no DomainParticipantQos can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 49 of file QosProviderImpl.hpp.

◆ participant_qos() [2/2]

dds::domain::qos::DomainParticipantQos dds::core::QosProvider::participant_qos ( const std::string & id )

Resolves the DomainParticipantQos identified by the id from the uri this QosProvider is associated with.

Parameters

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance. When id is NULL it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns: DomainParticipantQos from the given URI (and profile) using the id

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no DomainParticipantQos that matches the provided id can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 57 of file QosProviderImpl.hpp.

◆ publisher_qos() [1/2]

dds::pub::qos::PublisherQos dds::core::QosProvider::publisher_qos ( )

Resolves the PublisherQos from the uri this QosProvider is associated with.

Returns: PublisherQos from the given URI (and profile)

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no PublisherQos can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 114 of file QosProviderImpl.hpp.

◆ publisher_qos() [2/2]

dds::pub::qos::PublisherQos dds::core::QosProvider::publisher_qos ( const std::string & id )

Resolves the PublisherQos identified by the id from the uri this QosProvider is associated with.

Parameters

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance. When id is NULL it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns: PublisherQos from the given URI (and profile) using the id

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no PublisherQos that matches the provided id can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 122 of file QosProviderImpl.hpp.

◆ subscriber_qos() [1/2]

dds::sub::qos::SubscriberQos dds::core::QosProvider::subscriber_qos ( )

Resolves the SubscriberQos from the uri this QosProvider is associated with.

Returns: SubscriberQos from the given URI (and profile)

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no SubscriberQos can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 82 of file QosProviderImpl.hpp.

◆ subscriber_qos() [2/2]

dds::sub::qos::SubscriberQos dds::core::QosProvider::subscriber_qos ( const std::string & id )

Resolves the SubscriberQos identified by the id from the uri this QosProvider is associated with.

Parameters

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance. When id is NULL it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns: SubscriberQos from the given URI (and profile) using the id

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no SubscriberQos that matches the provided id can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 90 of file QosProviderImpl.hpp.

◆ topic_qos() [1/2]

dds::topic::qos::TopicQos dds::core::QosProvider::topic_qos ( )

Resolves the TopicQos from the uri this QosProvider is associated with.

Returns: TopicQos from the given URI (and profile)

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no TopicQos can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 65 of file QosProviderImpl.hpp.

◆ topic_qos() [2/2]

dds::topic::qos::TopicQos dds::core::QosProvider::topic_qos ( const std::string & id )

Resolves the TopicQos identified by the id from the uri this QosProvider is associated with.

Parameters

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance. When id is NULL it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns: TopicQos from the given URI (and profile) using the id

Exceptions

dds::core::Error	An internal error has occurred.
dds::core::PreconditionNotMetError	If no TopicQos that matches the provided id can be found within the uri associated with the QosProvider.
dds::core::OutOfResourcesError	The Data Distribution Service ran out of resources to complete this operation.

Definition at line 73 of file QosProviderImpl.hpp.

The documentation for this class was generated from the following files:

include/dcps/C++/isocpp2/dds/core/QosProvider.hpp
include/dcps/C++/isocpp2/dds/core/detail/QosProviderImpl.hpp

Public Member Functions

Detailed Description

Constructor & Destructor Documentation

◆ QosProvider() [1/2]

◆ QosProvider() [2/2]

Member Function Documentation

◆ datareader_qos() [1/2]

◆ datareader_qos() [2/2]

◆ datawriter_qos() [1/2]

◆ datawriter_qos() [2/2]

◆ is_nil()

◆ operator!=() [1/2]

◆ operator!=() [2/2]

◆ operator->() [1/2]

◆ operator->() [2/2]

◆ operator==() [1/2]

◆ operator==() [2/2]

◆ participant_qos() [1/2]

◆ participant_qos() [2/2]

◆ publisher_qos() [1/2]

◆ publisher_qos() [2/2]

◆ subscriber_qos() [1/2]

◆ subscriber_qos() [2/2]

◆ topic_qos() [1/2]

◆ topic_qos() [2/2]
