This class is the abstract base class for all the DCPS objects. More...
#include "Entity.hpp"
Public Member Functions | |
| void | close () |
| void | enable () |
| const dds::core::InstanceHandle | instance_handle () const |
| bool | is_nil () const |
| template<typename R > | |
| bool | operator!= (const R &ref) const |
| bool | operator!= (const null_type nil) const |
| DELEGATE * | operator-> () |
| const DELEGATE * | operator-> () const |
| template<typename R > | |
| bool | operator== (const R &ref) const |
| bool | operator== (const null_type) const |
| void | retain () |
| const dds::core::status::StatusMask | status_changes () |
This class is the abstract base class for all the DCPS objects.
This class is the abstract base class for all of the DCPS objects that support QoS policies a listener and a status condition:
In the ISO C++ PSM each DDS entity behaves like a polymorphic reference in that it automatically manages its resource and it can be safely assigned up and down the DDS Entity type hierarchy.
Definition at line 55 of file Entity.hpp.
| void dds::core::Entity::close | ( | ) |
This function closes the entity and releases related resources.
Resource management for some reference types might involve relatively heavyweight operating- system resources — such as e.g., threads, mutexes, and network sockets — in addition to memory. These objects therefore provide a method close() that shall halt network communication (in the case of entities) and dispose of any appropriate operating-system resources.
Users of this PSM are recommended to call close on objects of all reference types once they are finished using them. In addition, implementations may automatically close objects that they deem to be no longer in use, subject to the following restrictions:
Definition at line 68 of file EntityImpl.hpp.
| void dds::core::Entity::enable | ( | ) |
Enable entity.
This operation enables the Entity. Entity objects can be created either enabled or disabled. This is controlled by the value of the dds::core::policy::EntityFactory QoS policy on the corresponding factory for the Entity.
Enabled entities are immediately activated at creation time meaning all their immutable QoS settings can no longer be changed. Disabled Entities are not yet activated, so it is still possible to change there immutable QoS settings. However, once activated the immutable QoS settings can no longer be changed.
Creating disabled entities can make sense when the creator of the Entity does not yet know which QoS settings to apply, thus allowing another piece of code to set the QoS later on.
The default setting of dds::core::policy::EntityFactory is such that, by default, it is not necessary to explicitly call enable on newly- created entities.
The enable operation is idempotent. Calling enable on an already- enabled Entity does not raise exceptions and has no effect.
If an Entity has not yet been enabled, the only operations that can be invoked on it are: the ones to set, get or copy the QosPolicy settings, the ones that set (or get) the listener, the ones that get the StatusCondition, the get_status_changes operation (although the status of a disabled entity never changes), and the ‘factory’ operations that create, delete or lookup other Entities. Other operations will throw the exception dds::core::NotEnabledError.
Entities created from a factory that is disabled are created disabled regardless of the setting of the dds::core::policy::EntityFactory Qos policy. Calling enable on an Entity whose factory is not enabled will fail and throw an dds::core::PreconditionNotMetError exception.
If the dds::core::policy::EntityFactory QoS policy has autoenable_created_entities set to TRUE, the enable operation on the factory will automatically enable all entities created from the factory.
The Listeners associated with an entity are not called until the entity is enabled. Conditions associated with an entity that is not enabled are inactive; that is, they have a trigger_value==false (dds::core::cond::Condition and dds::core::cond::WaitSet).
eg.
In addition to the general description, the enable operation on a dds::sub::Subscriber has special meaning in specific usecases. This applies only to Subscribers with PresentationQoS coherent-access set to true with access-scope set to group.
In this case the subscriber is always created in a disabled state, regardless of the auto-enable created entities setting on the corresponding participant. While the subscriber remains disabled, DataReaders can be created that will participate in coherent transactions of the subscriber.
See dds::sub::CoherentAccess for more information.
All DataReaders will also be created in a disabled state. Coherency with group access-scope requires data to be delivered as a transaction, atomically, to all eligible readers. Therefore data should not be delivered to any single DataReader immediately after it's created, as usual, but only after the application has finished creating all DataReaders for a given Subscriber. At this point, the application should enable the Subscriber which in turn enables all its DataReaders.
Note that for a dds::pub::DataWriter which has a corresponding dds::pub::Publisher with a PresentationQoS with coherent-access set to true and access-scope set to topic or group that the HistoryQoS of the dds::pub::DataWriter should be set to keep-all otherwise the enable operation will fail.
See dds::pup::DataWriter for more information.
| dds::core::PreconditionNotMetError | Entities' factory is not enabled. |
Definition at line 44 of file EntityImpl.hpp.
| const dds::core::InstanceHandle dds::core::Entity::instance_handle | ( | ) | const |
This operation returns the InstanceHandle_t that represents the Entity.
The relevant state of some Entity objects are distributed using built-in topics. Each built-in topic sample represents the state of a specific Entity and has a unique instance_handle. This operation returns the instance_handle of the built-in topic sample that represents the specified Entity.
Some Entities (dds::pub::Publisher and dds::sub::Subscriber) do not have a corresponding built-in topic sample, but they still have an instance_handle that uniquely identifies the Entity. The instance_handles obtained this way can also be used to check whether a specific Entity is located in a specific DomainParticipant (dds::domain::DomainParticipant::contains_entity()).
Definition at line 60 of file EntityImpl.hpp.
|
inherited |
Check if the referenced object is nil.
In other words, check if the reference is pointing to a null object.
Definition at line 143 of file ReferenceImpl.hpp.
|
inherited |
Compares two Reference objects and returns true if they are not equal.
Inequality is based on the referential inequality of the object being pointed to.
| ref | the other Reference object |
Definition at line 100 of file ReferenceImpl.hpp.
|
inherited |
Special operator!= used to check if this reference object does not equal the dds::core::null reference.
The non-null-check can be done like this:
Definition at line 157 of file ReferenceImpl.hpp.
|
inherited |
The operator->() is provided to be able to directly invoke functions on the delegate.
The decision to provide direct access to the delegate was motivated by the need for providing a way that was not invasive with respect to the CXXDDS API and yet would allow for vendor-specific extension. Thus vendor-specific extensions can be invoked on the Reference and on all its subclasses as follows:
Definition at line 180 of file ReferenceImpl.hpp.
|
inherited |
The operator->() is provided to be able to directly invoke functions on the delegate.
The decision to provide direct access to the delegate was motivated by the need for providing a way that was not invasive with respect to the CXXDDS API and yet would allow for vendor-specific extension. Thus vendor-specific extensions can be invoked on the Reference and on all its subclasses as follows:
Definition at line 188 of file ReferenceImpl.hpp.
|
inherited |
Compares two Reference objects and returns true if they are equal.
Equality is based on the referential equality of the object being pointed.
| ref | the other Reference object |
Definition at line 83 of file ReferenceImpl.hpp.
|
inherited |
Special operator== used to check if this reference object equals the dds::core::null reference.
The null-check can be done like this:
Definition at line 150 of file ReferenceImpl.hpp.
| void dds::core::Entity::retain | ( | ) |
Retain the Entity, even when it goes out of scope.
This function indicates that references to this object may go out of scope but that the application expects to look it up again later. Therefore the Service must consider this object to be still in use and may not close it automatically.
Definition at line 76 of file EntityImpl.hpp.
| const dds::core::status::StatusMask dds::core::Entity::status_changes | ( | ) |
This operation returns a mask with the communication statuses in the Entity that are “triggered”.
This operation retrieves the list of communication statuses in the Entity that are triggered. That is the set of communication statuses whose value have changed since the last time the application called this operation. This operation shows whether a change has occurred even when the status seems unchanged because the status changed back to the original status.
When the Entity is first created or if the Entity is not enabled, all communication statuses are in the “un-triggered” state so the mask returned by the operation is empty.
The result value is a bit mask in which each bit shows which value has changed. The relevant bits represent one of the following statuses:
When the entity is first created, or if the entity is not enabled, all communication statuses are in the untriggered state so the list returned by the status_changes operation will be empty.
Each status bit is declared as a constant and can be used in an AND operation to check the status bit against the result of type StatusMask. Not all statuses are relevant to all Entity objects. See the respective Listener interfaces for each Entity for more information.
The list of statuses returned by the status_changes operation refers to the statuses that are triggered on the Entity itself, and does not include statuses that apply to contained entities.
Definition at line 52 of file EntityImpl.hpp.
