org::opensplice::topic::TopicListener< T > Class Template Reference

Topic proprietary events Listener. More...

#include "ProprietaryApi.hpp"

Inheritance diagram for org::opensplice::topic::TopicListener< T >:

Public Member Functions
virtual void	on_all_data_disposed (dds::topic::Topic< T > &topic, const org::opensplice::core::status::AllDataDisposedTopicStatus &status)=0
virtual void	on_inconsistent_topic (Topic< T > &topic, const dds::core::status::InconsistentTopicStatus &status)=0

Detailed Description

template<typename T>
class org::opensplice::topic::TopicListener< T >

Topic proprietary events Listener.

Since a Topic is an Entity, it has the ability to have a Listener associated with it. In this case, the associated Listener should be of type TopicListener. This interface must be implemented by the application. A user-defined class must be provided by the application which must extend from the TopicListener class.

This proprietary listener is a child of the specification listener and is made available to be able to trigger the on_all_data_disposed() proprietary event.

All operations for this interface must be implemented in the user-defined class, it is up to the application whether an operation is empty or contains some functionality.

The TopicListener provides a generic mechanism (actually a callback function) for the Data Distribution Service to notify the application of relevant asynchronous status change events, such as a missed deadline, violation of a QosPolicy setting, etc. The TopicListener is related to changes in communication status StatusConditions.

// Application example listener
class ExampleListener :
               public virtual org::opensplice::topic::TopicListener<Foo::Bar>
{
public:
    virtual void on_all_data_disposed (
        dds::topic::Topic<Foo::Bar>& topic,
        const org::opensplice::core::status::AllDataDisposedTopicStatus& status)
    {
        std::cout << "on_all_data_disposed" << std::endl;
    }

    virtual void on_inconsistent_topic (
        dds::topic::Topic<Foo::Bar>& topic,
        const dds::core::status::InconsistentTopicStatus& status)
    {
        std::cout << "on_inconsistent_topic" << std::endl;
    }
};

// Create Topic with the listener
dds::domain::DomainParticipant participant(org::opensplice::domain::default_id());
dds::topic::Topic<Foo::Bar> topic(participant,
                                  "TopicName",
                                  participant.default_topic_qos(),
                                  new ExampleListener(),
                                  dds::core::status::StatusMask::all());

See also

Topic

Listener information

Definition at line 127 of file ProprietaryApi.hpp.

Member Function Documentation

on_all_data_disposed()

template<typename T>

virtual void org::opensplice::topic::TopicListener< T >::on_all_data_disposed ( dds::topic::Topic< T > &  topic, const org::opensplice::core::status::AllDataDisposedTopicStatus &  status  )

pure virtual

This operation is called by the Data Distribution Service when the AllDataDisposedTopicStatus changes.

The implementation may be left empty when this functionality is not needed. This operation will only be called when the relevant TopicListener is installed and enabled with the dds::core::status::StatusMask::all_data_disposed_topic(). The AllDataDisposedTopicStatus will change when the node has completed disposal of data as a result of a call to dds::topic::AnyTopic::dispose_all_data().

Parameters

topic	contain a pointer to the Topic on which the conflict occurred (this is an input to the application).
status	contain the AllDataDisposedTopicStatus object (this is an input to the application).

on_inconsistent_topic()

template<typename T>

virtual void dds::topic::TopicListener< T >::on_inconsistent_topic ( Topic< T > &  topic, const dds::core::status::InconsistentTopicStatus &  status  )

pure virtualinherited

This operation is called by the Data Distribution Service when the InconsistentTopicStatus changes.

The implementation may be left empty when this functionality is not needed. This operation will only be called when the relevant TopicListener is installed and enabled with the StatusMask::inconsistent_topic(). The InconsistentTopicStatus will change when another Topic exists with the same topic_name but different characteristics.

Parameters

topic	contain a pointer to the Topic on which the conflict occurred (this is an input to the application).
status	contain the InconsistentTopicStatus object (this is an input to the application).

---

The documentation for this class was generated from the following file:

• include/dcps/C++/isocpp2/dds/core/detail/ProprietaryApi.hpp
