Create a QosProvider fetching QoS configuration from the specified URI. More...

Inheritance diagram for DDS.QosProvider:

Collaboration diagram for DDS.QosProvider:

Public Member Functions
	QosProvider (string uri, string profile)
	Constructs a new QosProvider based on the provided uri and profile. More...

ReturnCode	GetDataReaderQos (ref DataReaderQos datareaderQos, string id)
	Resolves the DataReaderQos identified by the id from the uri this QosProvider is associated with. More...

ReturnCode	GetDataWriterQos (ref DataWriterQos datawriterQos, string id)
	Resolves the DataWriterQos identified by the id from the uri this QosProvider is associated with. More...

ReturnCode	GetParticipantQos (ref DomainParticipantQos participantQos, string id)
	Resolves the DomainParticipantQos identified by the id from the uri this QosProvider is associated with. More...

ReturnCode	GetPublisherQos (ref PublisherQos publisherQos, string id)
	Resolves the PublisherQos identified by the id from the uri this QosProvider is associated with. More...

ReturnCode	GetSubscriberQos (ref SubscriberQos subscriberQos, string id)
	Resolves the SubscriberQos identified by the id from the uri this QosProvider is associated with. More...

ReturnCode	GetTopicQos (ref TopicQos topicQos, string id)
	Resolves the TopicQos identified by the id from the uri this QosProvider is associated with. More...

Detailed Description

Create a QosProvider fetching QoS configuration from the specified URI.

For instance, the following code:

DDS.QosProvider xml_file_provider("file://somewhere/on/disk/qos-config.xml", null);
DDS.QosProvider json_file_provider("file://somewhere/on/disk/json-config.json", null);
DDS.QosProvider json_http_provider("http:///somewhere.org/here/json-config.json", null);

The URI determines the how the Qos configuration is fetched and the format in which it is represented. This specification requires compliant implementations to support at least one file based configuration using the XML syntax defined as part of the DDS for CCM specification (formal/12.02.01).

Then you can extract QoS Policies from the QosProvider

/* Create QoS Policies. */
DDS.DomainParticipantQos parQos = new DDS.DomainParticipantQos();
DDS.TopicQos             tpcQos = new DDS.TopicQos();
DDS.SubscriberQos        subQos = new DDS.SubscriberQos();
DDS.DataReaderQos        rdrQos = new DDS.DataReaderQos();
DDS.PublisherQos         pubQos = new DDS.PublisherQos();
DDS.DataWriterQos        wrtQos = new DDS.DataWriterQos();
/* Set the QoS Policies according to the QosProvider XML content. */
DDS.QosProvider qosProvider("file://somewhere/on/disk/qos-config.xml", string.Empty);
/* Expect the functions to return ReturnCode.Ok. */
qosProvider.GetParticipantQos(ref parQos, null);
qosProvider.GetTopicQos      (ref tpcQos, null);
qosProvider.GetSubscriberQos (ref subQos, null);
qosProvider.GetDataReaderQos (ref rdrQos, null);
qosProvider.GetPublisherQos  (ref pubQos, null);
qosProvider.GetDataWriterQos (ref wrtQos, null);

See also: QoS Provider extensive information.

Definition at line 69 of file QosProvider.cs.

Constructor & Destructor Documentation

◆ QosProvider()

DDS.QosProvider.QosProvider	(	string	uri,
		string	profile
	)

inline

Constructs a new QosProvider based on the provided uri and profile.

A QosProvider instance that is instantiated with all profiles and/or QoS’s loaded from the location specified by the provided uri.

Initialization of the QosProvider will fail under the following conditions:

No uri is provided.
The resource pointed to by uri cannot be found.
The content of the resource pointed to by uri is malformed (e.g., malformed XML). When initialization fails (for example, due to a parse error or when the resource identified by uri cannot be found), then System.NullReferenceException will be thrown.

Look here for more information.

Parameters

uri	A Uniform Resource Identifier (URI) that points to the location where the QoS profile needs to be loaded from. Currently only URI’s with a ‘file’ scheme that point to an XML file are supported. If profiles and/or QoS settings are not uniquely identifiable by name within the resource pointed to by uri, a random one of them will be stored.
profile	The name of the QoS profile within the xml file that serves as the default QoS profile for the get qos operations.

Returns: New initialized QosProvider

Definition at line 136 of file QosProvider.cs.

Member Function Documentation

◆ GetDataReaderQos()

ReturnCode DDS.QosProvider.GetDataReaderQos	(	ref DataReaderQos	datareaderQos,
		string	id
	)

inline

Resolves the DataReaderQos identified by the id from the uri this QosProvider is associated with.

Parameters

datareaderQos Reference to a DataReaderQos that will be set with the DataReaderQos from the given URI (and profile) using the id.

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance.
When id is null, it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns

Return codes are:

DDS.ReturnCode Ok - The DataReaderQos was found and set in datareaderQos.
DDS.ReturnCode Error - An internal error has occurred.
DDS.ReturnCode PreconditionNotMetError - No DataReaderQos that matches the provided id can be found within the uri associated with the QosProvider.
DDS.ReturnCode OutOfResources - The DDS ran out of resources to complete this operation.

Definition at line 353 of file QosProvider.cs.

◆ GetDataWriterQos()

ReturnCode DDS.QosProvider.GetDataWriterQos	(	ref DataWriterQos	datawriterQos,
		string	id
	)

inline

Resolves the DataWriterQos identified by the id from the uri this QosProvider is associated with.

Parameters

datawriterQos Reference to a DataWriterQos that will be set with the DataWriterQos from the given URI (and profile) using the id.

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance.
When id is null, it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns

Return codes are:

DDS.ReturnCode Ok - The DataWriterQos was found and set in datawriterQos.
DDS.ReturnCode Error - An internal error has occurred.
DDS.ReturnCode PreconditionNotMetError - No DataWriterQos that matches the provided id can be found within the uri associated with the QosProvider.
DDS.ReturnCode OutOfResources - The DDS ran out of resources to complete this operation.

Definition at line 443 of file QosProvider.cs.

◆ GetParticipantQos()

ReturnCode DDS.QosProvider.GetParticipantQos	(	ref DomainParticipantQos	participantQos,
		string	id
	)

inline

Resolves the DomainParticipantQos identified by the id from the uri this QosProvider is associated with.

Parameters

participantQos Reference to a DomainParticipantQos that will be set with the DomainParticipantQos from the given URI (and profile) using the id.

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance.
When id is null, it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns

Return codes are:

DDS.ReturnCode Ok - The DomainParticipantQos was found and set in participantQos.
DDS.ReturnCode Error - An internal error has occurred.
DDS.ReturnCode PreconditionNotMetError - No DomainParticipantQos that matches the provided id can be found within the uri associated with the QosProvider.
DDS.ReturnCode OutOfResources - The DDS ran out of resources to complete this operation.

Definition at line 221 of file QosProvider.cs.

◆ GetPublisherQos()

ReturnCode DDS.QosProvider.GetPublisherQos	(	ref PublisherQos	publisherQos,
		string	id
	)

inline

Resolves the PublisherQos identified by the id from the uri this QosProvider is associated with.

Parameters

publisherQos Reference to a PublisherQos that will be set with the PublisherQos from the given URI (and profile) using the id.

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance.
When id is null, it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns

Return codes are:

DDS.ReturnCode Ok - The PublisherQos was found and set in publisherQos.
DDS.ReturnCode Error - An internal error has occurred.
DDS.ReturnCode PreconditionNotMetError - No PublisherQos that matches the provided id can be found within the uri associated with the QosProvider.
DDS.ReturnCode OutOfResources - The DDS ran out of resources to complete this operation.

Definition at line 398 of file QosProvider.cs.

◆ GetSubscriberQos()

ReturnCode DDS.QosProvider.GetSubscriberQos	(	ref SubscriberQos	subscriberQos,
		string	id
	)

inline

Resolves the SubscriberQos identified by the id from the uri this QosProvider is associated with.

Parameters

subscriberQos Reference to a SubscriberQos that will be set with the SubscriberQos from the given URI (and profile) using the id.

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance.
When id is null, it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns

Return codes are:

DDS.ReturnCode Ok - The SubscriberQos was found and set in subscriberQos.
DDS.ReturnCode Error - An internal error has occurred.
DDS.ReturnCode PreconditionNotMetError - No SubscriberQos that matches the provided id can be found within the uri associated with the QosProvider.
DDS.ReturnCode OutOfResources - The DDS ran out of resources to complete this operation.

Definition at line 309 of file QosProvider.cs.

◆ GetTopicQos()

ReturnCode DDS.QosProvider.GetTopicQos	(	ref TopicQos	topicQos,
		string	id
	)

inline

Resolves the TopicQos identified by the id from the uri this QosProvider is associated with.

Parameters

topicQos Reference to a TopicQos that will be set with the TopicQos from the given URI (and profile) using the id.

id The fully-qualified name that identifies a QoS within the uri associated with the QosProvider or a name that identifies a QoS within the uri associated with the QosProvider instance relative to its default QoS profile. Id’s starting with ‘::’ are interpreted as fully-qualified names and all others are interpreted as names relative to the default QoS profile of the QosProvider instance.
When id is null, it is interpreted as a non-named QoS within the default QoS profile associated with the QosProvider.

Returns

Return codes are:

DDS.ReturnCode Ok - The TopicQos was found and set in topicQos.
DDS.ReturnCode Error - An internal error has occurred.
DDS.ReturnCode PreconditionNotMetError - No TopicQos that matches the provided id can be found within the uri associated with the QosProvider.
DDS.ReturnCode OutOfResources - The DDS ran out of resources to complete this operation.

Definition at line 265 of file QosProvider.cs.

The documentation for this class was generated from the following file:

src/api/dcps/sacs/code/DDS/QosProvider.cs
